High Speed Folding and Gluing Machine:
We are manufacturing and supplying high speed carton folding and
gluing machines for pharma, FMCG, electrical goods boxes, CFL tube cartons etc
, in these machines particularly , We are incorporating HHS Gluing System(german)
for more accuracy and finish in gluing, as the small video of the machine is
available on the home page, For full video of the machine kindly contact the
or go to the link http://www.youtube.com/user/precisionmachinesind?feature=mhee
On this machine , very small cartons like : stapler sleeve, CFL sleeve , 10ml
syrup cartons to bulky cartons like: pharma outer cartons can be done with high
degree of accuracy, Tuck in type lock bottom cartons can be done with high
speed and accuracy and with very low changeover time.
Machine having following features:
HHS gluing system includes : encoder
for feedback ,hose pipe ,distributer , controller, 3 guns(dispenser) , pump and tank for glue , the guns having
photo electric sensors attached
Friction feeder with clutch drive for
independent functioning of the module(Electromagnetic type 24 vdc).
Digital counter for Batch, Total
product, and Number of pieces.
Main motor AC with AC variable digital
frequency drives system.
adjustment of tracks: The
tracks are based on exuberant German
design it adjust the thickness of the carton dramatically, In single setting
both duplex and three ply may run .
§ Robust Fabricated Structure: It is made from heavy
grounded 16mm thickness plates so
that at high speed the machine may not vibrate
§ Imported anti-vibration pads are used for leveling and for
vibration free operation
§ Imported Belts for
the tracks are used(i.e. nylon sandwich belt)
§ Glue tank with S.S. body, wheel hard chromium plated.
§ Variable speed of the end press section through variable dia
pully so that the length of the carton could be adjusted easily before final
§ Electromagnetic Striker For Making Batches, it has fast
response time and can be adjusted very easily for both A & B side of the
§ Four fold of the carton is possible and we ensure that there
should be proper spring action in the carton for automatic filling of the
§ All sealed bearings for avoiding jamming by paper dust
§ Compressor for HHS gluing system of 6 CFM with FRL unit.
§ Extended slow final pressing with upper conveyor friction
Main Technical Specification
Maximum line speed : 350mts/min
Net Weight :2500kg to 3500kg (according to the size of m/c)
Motor Power :5hp to 7.5hp(AC)
Auto Clutch coil volts : 24 volt dc
Motor Drive : Variable Frequency Drive 3Ã¸,440 volt
Striker Coil Volts: 230 Volts AC.
Carton feeding: Friction Type
Total general space working space required 25ft x 7ft.(*)
Readily available sizes of the machine 350mm,450mm and 550mm(**)
Compressor motor 2 hp, air capacity 6 cfm.
(*) length and width can be customize according to the
(**) Special sizes can be created as per demand.
Folding method : First folding line is 120
degree, third folding line is 95 degree, and second and fourth folding line is
180 degree in straight line boxes, In this way 4 fold is possible.
